Set up widgets the UltraScan way. More...

#include "us_widgets_dialog.h"

Inheritance diagram for US_WidgetsDialog:

Collaboration diagram for US_WidgetsDialog:

Public Member Functions
	US_WidgetsDialog (QWidget *, Qt::WindowFlags)

QLabel *	us_label (const QString &, int=0, int=QFont::Bold)

QLabel *	us_textlabel (const QString &, int=-1, int=QFont::Bold)

QLabel *	us_banner (const QString &, int=0, int=QFont::Bold)

QPushButton *	us_pushbutton (const QString &, bool=true, int=0)

QTextEdit *	us_textedit (void)

QLineEdit *	us_lineedit (const QString &=0, int=0, bool=false)

void	us_setReadOnly (QLineEdit *, bool=true)

void	us_setReadOnly (QTextEdit *, bool=true)

QListWidget *	us_listwidget (int=0)

QGridLayout *	us_checkbox (const QString &, QCheckBox *&, bool=false)

QGridLayout *	us_radiobutton (const QString &text, QRadioButton *&rb, bool state=false)

QProgressBar *	us_progressBar (int, int, int=0)

QComboBox *	us_comboBox (void)

QLCDNumber *	us_lcd (int, int=0)

QwtCounter *	us_counter (int, double, double, double=0.0)

QwtPlot *	us_plot (const QString &, const QString &=QString(), const QString &=QString())

QwtPlotGrid *	us_grid (QwtPlot *)

QwtPlotCurve *	us_curve (QwtPlot *, const QString &)

QwtPlotPicker *	us_picker (QwtPlot *)

QTabWidget *	us_tabwidget (int=0, int=QFont::Bold)

Public Attributes
US_Global	g
	Connect to global memory and make the values accessible. More...

QPalette	vlgray
	Very light gray palette for read-only line edits. More...

Detailed Description

Set up widgets the UltraScan way.

This class is designed to be the parent class to almost all UltraScan windows. It allows easy creation of widgets and applies the appropriate palette and font acording to the user's settings (or the UltraScan default). Depending on the widget, other parameters may be set.

Definition at line 23 of file us_widgets_dialog.h.

Constructor & Destructor Documentation

US_WidgetsDialog::US_WidgetsDialog	(	QWidget *	w,
		Qt::WindowFlags	f
	)

Parameters

w	- Parent widget, normally not specified
f	- Window flags, normally not specified

Definition at line 6 of file us_widgets_dialog.cpp.

Member Function Documentation

QLabel * US_WidgetsDialog::us_banner	(	const QString &	labelString,
		int	fontAdjust = `0`,
		int	weight = `QFont::Bold`
	)

Same as us_label except:

different default font weight (Bold )
color set to US_GuiSettings::frameColor()
alignment set to Qt::AlignCenter
style set to QFrame::WinPanel | QFrame::Raised
MidLineWidth set to 2 for frame border

Definition at line 56 of file us_widgets_dialog.cpp.

QGridLayout * US_WidgetsDialog::us_checkbox	(	const QString &	text,
		QCheckBox *&	cb,
		bool	state = `false`
	)

Parameters

text	- Text to set with checkbox
state	- checked – true or false
cb	- reference to a pointer of the checkbox Font weight is bold Color is set to US_GuiSettings::normalColor()

Definition at line 167 of file us_widgets_dialog.cpp.

QComboBox * US_WidgetsDialog::us_comboBox ( void )

Color is set to US_GuiSettings::normalColor()

Definition at line 250 of file us_widgets_dialog.cpp.

QwtCounter * US_WidgetsDialog::us_counter	(	int	buttons,
		double	low,
		double	high,
		double	value = `0.0`
	)

Parameters

buttons	- Number of buttons to use ( 1 to 3 )
low	- Lower bound of progress
high	- Upper bound of progress
value	- Initial value to set Color is set to US_GuiSettings::normalColor()

Definition at line 278 of file us_widgets_dialog.cpp.

QwtPlotCurve * US_WidgetsDialog::us_curve	(	QwtPlot *	plot,
		const QString &	title
	)

Parameters

plot*	- Pointer to plot
title	- Title of the curve Curve color is set to US_GuiSettings::plotCurve()

Definition at line 351 of file us_widgets_dialog.cpp.

QwtPlotGrid * US_WidgetsDialog::us_grid ( QwtPlot * plot )

Parameters

plot*

- Pointer to plot

Major Pen color is set to US_GuiSettings::plotMajGrid()
Minor Pen color is set to US_GuiSettings::plotMinGrid()

Definition at line 340 of file us_widgets_dialog.cpp.

QLabel * US_WidgetsDialog::us_label	(	const QString &	labelString,
		int	fontAdjust = `0`,
		int	weight = `QFont::Bold`
	)

Parameters

labelString	- contents of label
fontAdjust	- adjustment to default point size
weight	- QFont::{Light,Normal,DemiBold,Bold,Black} Alignment is set to Qt::AlignVCenter \| Qt::AlignLeft Margin is set to 5 Palette is set to US_GuiSettings::labelColor()

Definition at line 24 of file us_widgets_dialog.cpp.

QLCDNumber * US_WidgetsDialog::us_lcd	(	int	digits,
		int	value = `0`
	)

Create an LCD style disply

Parameters

digits	- Number of digits to display
value	- Initial value to set Color is set to US_GuiSettings::lcdColor()

Definition at line 263 of file us_widgets_dialog.cpp.

QLineEdit * US_WidgetsDialog::us_lineedit	(	const QString &	text = `0`,
		int	fontAdjust = `0`,
		bool	readonly = `false`
	)

Parameters

text	- starting text in line edit box
fontAdjust	- adjustment to default point size
readonly	- ReadOnly flag, default uses editColor()

Definition at line 106 of file us_widgets_dialog.cpp.

QListWidget * US_WidgetsDialog::us_listwidget ( int fontAdjust = 0 )

Parameters

fontAdjust

- adjustment to default font size

Color is set to US_GuiSettings::editColor()

Definition at line 154 of file us_widgets_dialog.cpp.

QwtPlotPicker * US_WidgetsDialog::us_picker ( QwtPlot * plot )

Parameters

plot*

- Pointer to plot

Rubber Band pen and Tracker pen color is set to
US_GuiSettings::plotPicker()

Definition at line 362 of file us_widgets_dialog.cpp.

QwtPlot * US_WidgetsDialog::us_plot	(	const QString &	title,
		const QString &	x_axis = `QString()`,
		const QString &	y_axis = `QString()`
	)

Parameters

title	- Plot Title
x_axis	- Bottom Axis Title
y_axis	- Left Axis Title Color is set to US_GuiSettings::plotColor() Convas background is set to US_GuiSettings::plotConvasBG()

Definition at line 322 of file us_widgets_dialog.cpp.

QProgressBar * US_WidgetsDialog::us_progressBar	(	int	low,
		int	high,
		int	value = `0`
	)

Parameters

low	- Lower bound of progress
high	- Upper bound of progress
value	- Initial value between low and high Color is set to US_GuiSettings::normalColor() Font weight is bold

Definition at line 231 of file us_widgets_dialog.cpp.

QPushButton * US_WidgetsDialog::us_pushbutton	(	const QString &	labelString,
		bool	enabled = `true`,
		int	fontAdjust = `0`
	)

Parameters

labelString	- text in pushbutton
enabled
fontAdjust	- adjustment to default font size Standard Font family and size color set to US_GuiSettings::pushbColor() button is enabled AutoDefault is set false

Definition at line 72 of file us_widgets_dialog.cpp.

QGridLayout * US_WidgetsDialog::us_radiobutton	(	const QString &	text,
		QRadioButton *&	rb,
		bool	state = `false`
	)

Create a radiobutton with a specifice palette (normal) and indentation of the button

Parameters

text	- Text to set with radiobutton
rb	- pointer to the radio button
state	- Checked ( true or false ) Color is set to US_GuiSettings::editColor()

Definition at line 199 of file us_widgets_dialog.cpp.

void US_WidgetsDialog::us_setReadOnly	(	QLineEdit *	le,
		bool	readonly = `true`
	)

Parameters

le	- line edit for which to reset ReadOnly flag/color
readonly	- ReadOnly flag, default uses vlgray

Definition at line 124 of file us_widgets_dialog.cpp.

void US_WidgetsDialog::us_setReadOnly	(	QTextEdit *	te,
		bool	readonly = `true`
	)

Parameters

te	- text edit for which to reset ReadOnly flag/color
readonly	- ReadOnly flag, default uses vlgray

Definition at line 139 of file us_widgets_dialog.cpp.

QTabWidget * US_WidgetsDialog::us_tabwidget	(	int	fontAdjust = `0`,
		int	weight = `QFont::Bold`
	)

Parameters

fontAdjust	- adjustment to default font size
weight	- QFont::{Light,Normal,DemiBold,Bold,Black} Color is set to US_GuiSettings::normalColor()

Definition at line 379 of file us_widgets_dialog.cpp.

QTextEdit * US_WidgetsDialog::us_textedit ( void )

Font size is set to default - 1
Color is set to US_GuiSettings::normalColor()
Style is WinPanel | Sunken
AcceptRichText is true
ReadOnly is true

Definition at line 89 of file us_widgets_dialog.cpp.

QLabel * US_WidgetsDialog::us_textlabel	(	const QString &	labelString,
		int	fontAdjust = `-1`,
		int	weight = `QFont::Bold`
	)

Same as us_label except:

different default font size (-1 point)
color set to US_GuiSettings::editColor()

Definition at line 45 of file us_widgets_dialog.cpp.

Member Data Documentation

US_Global US_WidgetsDialog::g

Connect to global memory and make the values accessible.

Definition at line 31 of file us_widgets_dialog.h.

QPalette US_WidgetsDialog::vlgray

Very light gray palette for read-only line edits.

Definition at line 34 of file us_widgets_dialog.h.

The documentation for this class was generated from the following files:
